Banana Pi BPI-M7 with Rockchip RK3588, 8/16/32G,RAM 64/128G eMMC,wifi6 support . 2×2.5G port ,1xHDMIout ,2x USB3.0,2xTYPE-C,2x MIPI CSI interface and 1x MIPI DSI interface, 1x M.2 KEY M interface,40 PIN GPIO ,Mini size just 92x62mm.
The Banana Pi BPI-M7 is powered by Rockchipās latest flagship RK3588,octa-core 64-bit processor, with a max frequency of 2.4GHz, a 6 TOPS NPU, and up to 32GB of RAM.
Banana Pi BPI-M7 RK3588 SBC Features:
* 8K video encoding/decoding support
* Abundant interfaces support
* Dual 2.5G Ethernet support
* WiFi 6 support
* BT 5 support
* Multiple video outputs support
* Multiple operating systems support
Generally, BPI-M7 is applied for various applications,such as, ARM PCs, edge computing, cloud servers, AI, cloud computing, virtual/augmented reality, blockchain, smart NVRs and more.
Technical Specifications
| Model/Type | Banana Pi – M7 ( 8G Ram + 64G eMMC ) |
| SOC | RockChip RK3588 |
| CPU | RK3588 Quad-Core Cortex-A76@ 2.4GHz+Quad-CoreCortex-A55@ 1.8GHzļ¼8nm process |
| GPU | GPU Mali-G610 MP4 (4x256KB L2 Cache) Supports OpenGL ES3.2/OpenCL2.2/Vulkan1.1 |
| NPU | 6 TOPS@INT8(3 NPU core) Supports INT4/INT8/INT16 mixed computing Supports frameworks like TensorFlow, MXNet, PyTorch, Caffe, Tflite, Onnx NN, Android NN, etc |
| VPU/Codec | Hardware Decode: 8K@60fps H.265/VP9/AVS2ć 8K@30fps H.264 AVC/MVCć 4K@60fps AV1ć1080P@60fps MPEG-2/-1/VC-1/VP8
Hardware Encode:8K@30fps H.265 / H.264 |
| ISP | Integrated 48MP ISP with HDR&3DNR |
| RAM | 8GB max 32GB ļ¼64bit LPDDR4/LPDDR4xļ¼default 8GB LPDDR4x |
| Flash | 32GB/64GB/128GB eMMCļ¼default 64GB eMMC,Supports MicroSD card expansion |
| PCIe | 1x M.2 Key M (PCIe 3.0 4-lanes). Expandable SSD support for 2280/2260/2242/2230 M.2 SSD cards, default 2280 |
| Networking | 2x 2.5G Ethernet Onboard IEEE 802.11a/b/g/n/ac/ax WIFI6 and BT5 (AP6275P) |
| Video Out | 1x HDMI 2.1, supports 8K@60fps 1x MIPI DSI up to 4K@60fps 1x DP 1.4 up to 8K@30fps |
| Video In | 2x 2-lane MIPI CSI, up to 2.5Gbps per lane |
| Audio | 1x HDMI audio out 1x HP audio out 1x Type-C 3.1 (DP1.4) audio out |
| USB | 1x USB 3.0 (USB 3.1 Gen 1), equivalent to USB 3.2 Gen 1/USB 3.0, up to 5Gbps 1x USB Type-C 3.1ļ¼DP1.4/OTGļ¼ 1x USB 2.0 Highļ¼480Mbpsļ¼/Fullļ¼12Mbpsļ¼/Low-Speedļ¼1.5Mbpsļ¼ modes |
| 40-pin | Fully compatible with Raspberry Pi 40-pin header for connecting abundant add-on modules Supports UART/SPI/I2C/I2S/PWM/ADC/5V Power/3.3V Power |
| Other | 1x 5V fan interface 1x battery connector for low power RTC chip HYM8563TS 2x LEDs – blue LED blinks on system start, red LED user controllable |
| Power Input | USB Type-C PD 2.0, 9V/2A, 12V/2A, 15V/2A |
| Buttons | 1x PWRON button for sleep/wake,1x Reset button for reboot,1x Maskrom button for maskrom burn-in mode |
| OS Support | Official: ļ¼Android 12.0ļ¼Debian11ļ¼Buildroot 3rd Partyļ¼Armbianļ¼Ubuntu 20.04ļ¼Ubuntu22.04ļ¼Kylin OS |
| Dimensions | 92 mm x 62mm |
| Operating temperature | 0ā ~ 80ā |
